Helukabel OZ-HF-CY 2x0.75 mm²x2x0.75 mm² – 15945

PVC drag chain cable acc. to DIN VDE 0285-525-2-51 / DIN EN 50525-2-51.

Technical Data:
• Nominal Voltage: AC U0/U 300/500 V
• Test Voltage: 4000 V
• Breakdown Voltage: 8000 V
• Temperature Range (flexible): -10°C to +80°C
• Temperature Range (fixed): -40°C to +80°C
• Coupling Resistance: approx. 250 Ohm/km at 30 MHz
• Minimum Bending Radius: 10x outer diameter (flexible) / 5x outer diameter (fixed)
• Braided tinned copper screen, approx. 85% coverage

Application:
Used for installation in dry and damp rooms, but not outdoors. Designed for drag chains in continuous motion, automatic handling machines, robots and permanently moving machine parts. Screened construction ensures interference-free signal transmission (EMC-optimised).
