Helukabel JB-500 25G 1 mm² 25x1.0 – 11070

Technical Data

• Standards: DIN VDE 0285-525-2-11 / DIN EN 50525-2-11
• Temperature range: flexible -15°C to +80°C; fixed -40°C to +80°C
• Nominal voltage: AC U0/U 300/500 V
• Test voltage core/core: 4000 V
• Breakdown voltage: 8000 V
• Minimum bending radius: flexible 7.5x Outer-Ø; fixed 4x Outer-Ø

Details

Cable Structure

• Copper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5
• Core insulation: PVC, compound type Z 7225
• Core identification acc. to JB/OB colour code, colour coded
• Protective conductor: starting with 3 cores (G = with protective conductor GN-YE, in the outer layer; X = without protective conductor (OB))
• Cores stranded in layers with optimal lay lengths
• Outer sheath: PVC acc. to DIN VDE 0207-363-4-1 / DIN EN 50363-4-1 (compound type TM2)
• Sheath colour: grey (RAL 7001)
• Length marking: in metres

Properties

• Largely resistant to: oil (for details, see “Technical Information”)
• Conditionally torsional
• Conditionally suitable for drag chains
• The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers

Tests

• Flame-retardant acc. to DIN VDE 0482-332-1-2 / DIN EN 60332-1-2 / IEC 60332-1-2
• Certifications and approvals: EAC

Notes

• The conductor is metrically (mm²) constructed; AWG numbers are approximated and are for reference only
• Please note “cleanroom qualification” in your order

Application

Used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms; not suitable for outdoor use as a measuring and control cable in machine tools, assembly lines, conveyor belts, production lines, plant construction and in heating and air-conditioning technology.
